High - Precision & Efficient DC6050A CNC Copper Electrode Engraving and Milling Machine for Global Industries

Don't miss out on this top - notch DC6050A CNC Copper Electrode Engraving Milling Machine! Submit an inquiry now and take your copper electrode processing to the next level.
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111821/cnc-engraving-milling-machine-for--copper-electrode-dc6050a-1.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111821/cnc-engraving-milling-machine-for--copper-electrode-dc6050a-2.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111821/cnc-engraving-milling-machine-for--copper-electrode-dc6050a-3.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111821/cnc-engraving-milling-machine-for--copper-electrode-dc6050a-4.jpg

Recommended Products

Product Parameters
accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.005 mm
See more
Workbench
Work table size: 600*530mm
T-slot dimensions: 5T-12-105 mm
Maximum load: 250 kg
Processing range
X/Y/Z axis travel: 600/500/160 mm
Gantry width: 660 mm
Beam to workbench: 380 mm
Spindle nose to worktable: 170-330 mm
Door opening width: 600 mm
feed
Maximum feed speed G00: 15 m/min
Maximum processing speed G01: 10 m/min
X/Y/Z axis motor power: 750W/750W/750W
Spindle
Spindle motor power: 3 kW
Maximum spindle speed: 21000 rpm
Tool holder: ER20(Φ3.17-Φ12)
Spindle diameter: 110 mm
Common
Power supply and total capacity: 3P/380V/50Hz/9KVA
Machine weight: 2500 kg
aspect: 1850*1800*1910mm
Main Components
Controller: Syntec 21MA/Taiwan
AC servo motor (driver): Yaskawa/Japan
Spindle inverter: Innovation/China
Linear Guides: 30 Hiwin, PMI/Taiwan
Ball Screw: 2505 Hiwin, PMI/Taiwan
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2 ISHAN/Taiwan
Oil Cooler: Opt.Parsonthor/China
Pneumatic system: AirTac/Taiwan
Chip conveyor:
Water tank capacity: 99L
Water pump power: 220W
Tool magazine (optional)
ATC Type: Straight
Air traffic control capabilities: 6 items
Close
Product Details
Product Introduction
The DC6050A copper electrode CNC engraving and milling machine carefully built by Ningbo Kaibo CNC Machinery Co., Ltd. is tailored for precision engraving and milling tasks. As the setter of the national standard for "CNC engraving and milling machine", Kaibo CNC has a good reputation in the industry with its strong R&D capabilities and high-quality products. The machine tool has excellent processing accuracy and high performance, can efficiently process aluminum molds and metal products, and optimize precision steel engraving processes. It has a high-rigidity structure and advanced control system to ensure stable processing and extremely high repeatability. It is especially suitable for copper electrode processing with complex shapes, effectively solving engraving problems. In addition, the company has service offices in many markets around the world, which can provide comprehensive after-sales support to international customers and promote the sustainable development of the industry.
Product Introduction
Advantages and features
1. Excellent processing accuracy to meet the needs of precision processing.
2. High efficiency performance, able to quickly complete various processing tasks.
3. High rigidity structure ensures stable processing.
4. Advanced control system to achieve extremely high repeatability.
5. Strong R&D support, guaranteed product quality. 6. Global after-sales network, providing comprehensive service support.
Application Scenario
This copper electrode CNC engraving and milling machine DC6050A is suitable for industries that require precision engraving and milling, such as mold manufacturing, electronics, mechanical processing, etc. It is suitable for customers around the world who have high requirements for processing accuracy and efficiency. Whether it is a large enterprise or a small and medium-sized enterprise, this machine can help improve production quality and efficiency.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
ER20/3kw/24000rpm electric spindle ER25/4.5kw/24000rpm electric spindle NBT30/4.5kw/24000rpm electric spindle HSK E25/3kw/40000rpm electric spindle More spindles
Tool magazine type
Straight knife magazine (6 pieces) Arm type tool magazine (20 pieces)

Payment method

L/C
L/C
T/T
T/T
D/P
D/P
D/A
D/A

Means of transaction

Communication
Direct Exporting
Indirect Exporting

Refunds

Contact us for details
