High - Efficiency Mitsubishi - Controlled FH1890L Vertical Machining Center for Heavy - Duty Large - Stroke Applications

Don't miss out on this game - changing machining solution! Contact us now to get a quote and take your production to the next level with the FH1890L Vertical Machining Center.
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807144348/big-travel-vmc-with-mitsubishi-controller-fh1890l-1.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807144348/big-travel-vmc-with-mitsubishi-controller-fh1890l-2.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807144348/big-travel-vmc-with-mitsubishi-controller-fh1890l-3.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807144348/big-travel-vmc-with-mitsubishi-controller-fh1890l-5.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240822101456/1724292907778_big-travel-vmc-with-mitsubishi-controller-fh1890l-4.png
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240822101512/1724292926165_big-travel-vmc-with-mitsubishi-controller-fh1890l-6.png

Recommended Products

Product Parameters
Accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.005 mm
See more
Workbench
working desk size: 1500*800mm
T-slot dimensions: 6T-18-125 mm
Maximum load: 3000 kg
Processing range
X/Y/Z axis travel: 1600*900*800mm
Spindle nose to worktable: 110-810 mm
Spindle center to column: 850 mm
Feed
Maximum feed speed G00: 20-20-15 m/min
Maximum processing speed G01: 8m/min
X/Y/Z axis motor power: 4.4/4.4/4.4 kW
Spindle
Drive Type: Direct
Spindle motor power: 18.5-22 kW
Maximum spindle speed: 6000 rpm
Tool holder: BT50
Tool magazine (optional)
ATC Type: Arm Type
Air traffic control capabilities: 24 items
Common
Power supply and total capacity: 3P/380V/50Hz/40KVA
Machine weight: 12000 kg
aspect: 4000*3000*3200mm
The main components
Controller: Syntec 21MA/Taiwan
AC servo motor (driver): Yaskawa/Japan
Spindle inverter: Innovation/China
guide: 45(6/8/6) Hiwin, PMI/Taiwan
Ball Screw: 5012 Hiwin, PMI/Taiwan
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2 ISHAN/Taiwan
Oil Cooler: Parsonshal/China
air conditioner: EA-6AP Parsonsall/China
Chip conveyor: Internal thread type
Close
Product Details
Product Introduction
Ningbo Kaibo CNC Machinery Co., Ltd., established in 1994, has been a pioneer in developing and manufacturing high - quality CNC machine tools. The FH1890L Vertical Machining Center is our latest offering, engineered for large - scale machining and heavy roughing. It comes with an advanced Mitsubishi controller, providing excellent precision and stability, which meets the modern manufacturing requirements of efficiency, precision, and timely delivery. The machine also features a range of optional accessories, enhancing its machining capabilities and flexibility. With top - notch R & D technology and comprehensive after - sales service, Kaibo CNC is committed to creating value for customers worldwide. Choose the FH1890L to optimize your production line.
Product Introduction
Advantages and features
1. Advanced Mitsubishi controller ensures high precision and stability. 2. Designed for large - scale machining and heavy roughing. 3. A variety of optional accessories like angular heads, universal heads, spindle extension rods, and probes enhance flexibility. 4. Backed by Ningbo Kaibo CNC Machinery Co., Ltd.'s top - tier R & D technology and comprehensive after - sales service.
Application Scenario
The FH1890L Vertical Machining Center is suitable for automotive parts manufacturing, large component production, and other heavy - machining industries. It caters to customers in manufacturing markets who demand high - precision, efficient, and heavy - duty machining solutions, whether they are small - scale workshops or large - scale manufacturing enterprises.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
BT50/18.5kw/6000-8000rpm mechanical spindle HSK A63/15kw/18000rpm electric spindle More spindles
Tool magazine type
Arm type tool magazine (24 pieces)
