Ningbo Kaibo's High-Precision GJ1417 CNC Mill for Premium Automotive Component Manufacturing

Elevate your automotive parts manufacturing to new heights with the GJ1417 CNC Milling Machine. Contact us now for a detailed quote and take the first step towards precision and efficiency in your production process!
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807143250/high-accuracy-cnc-milling-machine-for-stainless-steel-gj1417-1.jpg

Recommended Products

Product Parameters
Accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.008 mm
See more
Workbench
working desk size: 1700*1400mm
T-slot dimensions: 7T-18-190 mm
Maximum load: 3000 kg
Processing range
X/Y/Z axis travel: 1400/1700/720 mm
Spindle nose to worktable: 140-860 mm
Feed
Maximum feed speed G00: 20 m/min
Maximum processing speed G01: 8m/min
X/Y/Z axis motor power: Bis40/2000*2+bis40B/2000
Spindle
Spindle motor power: αilP40-18.5KW
Maximum spindle speed: 15000 rpm
Tool holder: HSK63
Spindle diameter: 120
Common
Power supply and total capacity: 3P/380V/50Hz/30KVA
Machine weight: 17000 kg
aspect: 4600*4600*3200mm
The main components
Controller: Fanuc/Japan 0i-MF
AC servo motor (driver): FANUC/Japan
Spindle inverter: FANUC/Japan
Linear Guides: Hiwin, PMI/Taiwan (45/45/45) 4 sliders on X axis, 6 sliders on Y and Z axis
Ball Screw: Hiwin, PMI/Taiwan (X, Y axis 5010; Z axis 4010)
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2 ISHAN/Taiwan
Oil Cooler: Parsonshal/China
air conditioner: EA-6AP Parsonsall/China
Chip conveyor: Internal thread type
Tool magazine (optional)
ATC Type: Arm Type
Air traffic control capabilities: 24 items
Close
Product Details
Product Introduction
The High-Precision CNC Milling Machine GJ1417, developed by Ningbo Kaibo CNC Machinery Co., Ltd., is a revolutionary gantry machining center tailored for the automotive parts manufacturing industry. Combining cutting - edge CNC technology with precise machining processes, it is engineered to meet the most exacting ultra - precision machining needs. Renowned for setting national standards in CNC milling machines, Kaibo CNC offers high - quality, reliable equipment. The GJ1417's robust structural design ensures unparalleled stability and precision during high - speed cutting operations. With exceptional machining accuracy and reliability, it has become a trusted choice for manufacturers worldwide. When you choose Kaibo CNC, you gain access to comprehensive sales and after - sales support, ensuring your business runs smoothly.
Product Introduction
Advantages and features
1. Advanced CNC technology enables ultra - precision machining. 2. Robust structural design guarantees stability and precision during high - speed cutting. 3. Exceptional machining accuracy and reliability, backed by a company that pioneers national standards. 4. Comprehensive sales and after - sales support to ensure seamless operation.
Application Scenario
This CNC milling machine is specifically designed for the automotive parts manufacturing industry. It is suitable for automotive component manufacturers of all sizes, whether they are large - scale production plants or small - to - medium - sized enterprises. It can be used to produce a wide range of automotive parts, including engine components, transmission parts, and chassis components. The machine is also suitable for markets in North America, Europe, Asia, and other regions where high - precision automotive parts are in high demand.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
HSK A63/11kw/24000rpm electric spindle HSK A63/15kw/18000rpm electric spindle More spindles
Tool magazine type
Arm type tool magazine (24 pieces)

Payment method

L/C
L/C
T/T
T/T
D/P
D/P
D/A
D/A

Means of transaction

Communication
Direct Exporting
Indirect Exporting

Refunds

Contact us for details
