Ningbo Kaibo DC6040D High-Precision Compact Gantry-Style CNC Engraving and Milling Machine for Small Manufacturers

Elevate your small-scale production with the DC6040D. Don't miss out on this high-precision CNC milling solution. Contact us now to place your order and experience industry-leading technology and service!
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111644/cnc-engraving-milling-machine-for-aluminum-dc6040d-1.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111644/cnc-engraving-milling-machine-for-aluminum-dc6040d-2.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111644/cnc-engraving-milling-machine-for-aluminum-dc6040d-3.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111644/cnc-engraving-milling-machine-for-aluminum-dc6040d-4.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807111644/cnc-engraving-milling-machine-for-aluminum-dc6040d-6.jpg

Recommended Products

Product Parameters
Accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.005 mm
See more
Workbench
working desk size: 625*450mm
T-slot dimensions: 4T-12-120 mm
Maximum load: 150 kg
Processing range
X/Y/Z axis travel: 600/400/170 mm
Gantry width: 705 mm
Beam to workbench: 300 mm
Spindle nose to worktable: 90-260 mm
Door opening width: 540 mm
Feed
Maximum feed speed G00: 15 m/min
Maximum processing speed G01: 10 m/min
X/Y/Z axis motor power: 750W/750W/750W
Spindle
Spindle motor power: 3 kW
Maximum spindle speed: 21000 rpm
Tool holder: ER20(Φ3.17-Φ12)
Spindle diameter: 85 mm
Common
Power supply and total capacity: 3P/380V/50Hz/9KVA
Machine weight: 2100 kg
aspect: 1910*1730*1910mm
The main components
Controller: Syntec 21MA/Taiwan
AC servo motor (driver): Yaskawa/Japan
Spindle inverter: Innovation/China
Linear Guides: 25 Hiwin, PMI/Taiwan
Ball Screw: 2005/2005/2505 Hiwin, PMI/Taiwan
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2 ISHAN/Taiwan
Oil Cooler: Opt.Parsonthor/China
air conditioner: Opt.Parsonthor/China
Pneumatic system: AirTac/Taiwan
Chip conveyor:
Water tank capacity: 95L
Water pump power: 220W
Tool magazine (optional)
ATC Type: Straight type
Air traffic control capabilities: 6 items
Close
Product Details
Product Introduction
The DC6040D aluminum alloy CNC milling machine carefully built by Ningbo Kaibo CNC Machinery Co., Ltd. is a high-precision small gantry CNC milling machine. As the developer of the national standard for "CNC milling machine", Kaibo CNC has always adhered to the concept of developing high-quality machine tools and meeting customer needs, providing high-quality services to the global market. The equipment is specially designed for precision aluminum mold manufacturing and metal product processing, equipped with an advanced CNC system. Even in the face of complex processes, it can maintain high efficiency and stability, greatly improving production efficiency. Moreover, each device undergoes strict quality inspection to ensure that it meets the high standards of customers, making it an ideal choice for small product manufacturers.
Product Introduction
Advantages and features
1. High precision: With excellent processing accuracy, it can meet the processing requirements of precision aluminum molds and metal products.
2. High rigidity: It has excellent rigidity to ensure the stability of the equipment during processing.
3. Advanced CNC system: Equipped with advanced CNC system, it can operate efficiently and stably in complex processes.
4. Strict quality inspection: Each device undergoes strict quality inspection and has reliable quality.
Application Scenario
This aluminum alloy CNC engraving and milling machine is suitable for precision aluminum mold manufacturing, metal product processing and other fields. It is suitable for customers such as small product manufacturers and metal processing companies, and can be widely used in machinery manufacturing, electronics, automotive parts and other markets.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
ER20/3kw/24000rpm electric spindle ER25/4.5kw/24000rpm electric spindle NBT30/4.5kw/24000rpm electric spindle HSK E25/3kw/40000rpm electric spindle More spindles
Tool magazine type
Straight tool magazine (6 pieces)

Payment method

L/C
L/C
T/T
T/T
D/P
D/P
D/A
D/A

Means of transaction

Communication
Direct Exporting
Indirect Exporting

Refunds

Contact us for details
